HMD Kontro CSA/CSI Chemical Service Pump

Sundyne HMD Kontro Magnetic Drive Pump Models CSA CSI

Leading Sealless Pump Performance for the Chemical Industry

The CSA / CSI is HMD Kontro’s newest range of chemical service sealless pumps with full compliance to ASME B73.3 and ISO 2858 / 15783 standards. Incorporating latest magnetic drive technology, the range features a simple, modular design with maximised interchangeability, high efficiency hydraulics and a number of upgrade options to ensure suitability with a wide range of applications.

The CSA / CSI range features different hydraulic sizes that conform to current ASME / ISO dimensional, performance and construction requirements. Close-coupled and separately mounted variants are available along with a wide range of options including secondary control or containment, instrumentation and various bearing isolation and lubrication options. The range is specifically designed for maximum part interchangeability, ease of onsite service and has a wide number of site upgradable features.

Key Design Features

Sealless Design: For total product containment, essential for hazardous, aggressive or valuable liquids
No Seals: Minimises maintenance and all of the associated costs, and eliminates potential leak paths
Modular Construction: With interchangeable components for maximum design coverage, reduced inventory needs and minimised lead times
High Efficiency Design: Providing reduced power consumption through optimised hydraulics and the Zeroloss Containment Shell option.
Site Serviceable Design: Facilitating ease of on-site maintenance activities with removable wear rings, simplified internal bearing replacement with no hot working required, bearing housing oil overfill protection and no requirements for special tools.
Robust Design: Featuring a single fully confined casing gasket, internal and external bump rings, and the Zeroloss containment shell option for increased tolerance to system upsets.
Secondary Control and Containment available as upgrade options across entire CSA / CSI and can be installed in both Close-Coupled and Separately Mounted configurations

  • Flows up to 1,408 GPM (320 m³/hr)
  • Heads to 490 ft (150 m)
  • Temperature Range -40 to 500°F (-40 to 260°C)
  • Design Pressure: 275 psi (18.9 bar) ASME; 232 psi (16 bar) ISO


Chemical Processing

  • Chlor-Alkali
  • Isocyanates/Polyurethane
  • Agri-chemicals
  • Fine / Inorganic Chemicals
  • Sulfuric Acid

Hydrocarbon Processing

  • Hydrocarbons
  • Olefins
  • Aromatics
  • Methanol
  • Ammonia
  • Amines
  • Sour Water
  • Caustic
  • Alkylation


  • Crude Oil
  • Sour Water
  • Caustic

Battery Manufacturing

  • Sulfuric acid
  • Potassium hydroxide


  • Bio-diesel
  • Ethanol

Food and Beverage

  • Edible Oils
  • Cocoa Butter


  • Sodium cyanide
  • Sulfuric acid
  • Hydrochloric acid


  • Silicon oil (Heat transfer fluid)

Pulp and Paper

  • Chlorine
  • Sulfuric Acid

Semiconductor Manufacturing

  • Sulfuric acid
  • Potassium Hydroxide

Water and Wastewater Treatment

  • Sodium hypochlorite
  • Sodium hydroxide
  • Sulfuric acid
  • Ferric Chloride

US 60 Hz

  • Heads to                                                  490 ft
  • Flows to                                                   1,408 gpm
  • Maximum Motor Power                           100 HP
  • Temperature Range                                -40 to 500°F
  • Design Pressure                                  275 psi ASME
  • Solids Range               Maximum of 5% w/w less than 150 microns
  • Motor Details                                           Industry standard
  • Mounting Configuration                           Horizontal close and long coupled
  • Dimensional Standards                         ASME B73.3
  • Available Flanges                                   150# RF
  • Materials                                                 316SS

Metric 50 Hz

  • Heads to                                                  150 m
  • Flows to                                                   320 m3/hr
  • Maximum Motor Power                           75 kW
  • Temperature Range                                -40 to 260°C
  • Design Pressure                                  16 bar ISO / 18.9 bar ASME
  • Solids Range                   Maximum of 5% w/w less than 150 microns
  • Motor Details                                     Industry Standard
  • Mounting Configuration               Horizontal close and long coupled
  • Dimensional Standards                       ISO 2858 / 15783 ASME B73.3
  • Available Flanges                                   150# RF, DIN 2543
  • Materials                                                      316SS
